- General Information
- Manufacturer
- Gefen, Inc
- Manufacturer Website Address
- http://www.gefen.com
- Brand Name
- Gefen
- Product Type
- KVM Console/Extender
Extra Long Range KVM Extender for DVI and USB over one Cat-5 cable
The DVIKVM ELR extends any DVI and USB source to a monitor, touch screen display, or other digital signage application over a distance up to 330 feet (100 meters) using one Cat-5 cable. USB 2.0 data rates up to 100 Mbps are supported in addition to backward-compatibility with USB 1.1. The Receiver unit allows the connections of up to three USB devices, providing access to printers, scanners, cameras, external storage media, digital signage, and automated control systems. This product uses Gefen ELR (Extra Long Range) technology, allowing DVI and USB signals to travel along the same CAT-5 cable, reducing cabling costs and facilitating easier installation.- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Connectivity Technology
- Wired
- KVM Technology
- Analog
- Number of Computers Supported
- 1
- Maximum Operating Distance
- 330 ft
- Video
- Graphic Mode
- WUXGA
- Maximum Video Resolution
- 1920 x 1200
- Interfaces/Ports
- Network (RJ-45)
- Yes
- USB
- Yes
- DVI
- Yes
- Number of Network (RJ-45) Ports
- 2
- Number of USB Ports
- 4
- Number of DVI Ports
- 2
- Power Description
- Input Voltage
- 5 V DC
- Power Consumption
- 10 W
- Physical Characteristics
- Rack Height
- 1U
- Form Factor
- Rack-mountable
- Transmitter Height
- 1.75"
- Transmitter Width
- 8.50"
- Transmitter Depth
- 4.50"
- Receiver Height
- 1.75"
- Receiver Width
- 8.50"
- Receiver Depth
- 4.50"
- Miscellaneous
- Package Contents
- DVIKVM Extra Long Range Extender
- 1 x 6ft.DVI Cable
- 1 x 6ft.USB Cable
- 2 x Locking Power Supplies
- 1 x User Manual
- 2 x AC Power Cord
